The Arca-DACS 100 (also "ACDX-100" or "A100") is a Compact Digital Access Cross Connect System that allows carriers to groom granularity from DS3 down to DS0 and to concentrate voice and data traffic before it hits the transport network, all in one efficient, small-footprint platform. The Arca-DACS 100 is OSMINE-certified and Network Equipment Building Standard (NEBS) Level-3 compliant. Verilink acquired the product line from Zhone in 2005, which was in turn was acquired by Verso Technologies in 2006. Verso later sold its family of access products, including the ArcaDACS system, to CTDI (Communications Test Design Inc) in 2008.
ARCA DACS 100 Reference Guide ARCA DACS 100 Data Sheet
| Part | HECI | Description | |
|---|---|---|---|
 |
920-00004-01-SA 716300 800-00004-01 9ZX-ACDX-IXCON-DM ACDX-IXCON-DM IXCON S300-IXCON-DM SNPQCBZNAA | SNU4EF0 SNU4EF0BAA | INTELLIGENT CROSS CONNECT CARD |
 |
920-00009-01 9ZX-ACDX-CHASSIS SYSC | SNMXY00 SNMXY00GRA | 17 SLOT SYSTEM CHASSIS W/ SYSC, SYS BP, BRAC, BEZ, C TRAY, FCAPF |
 |
920-00706-01 9ZX-ACDX-CT3R-DM ACDX-CT3R-DM S300-CT3R-DM | SNU4CD0 SNU4CD0BAA | 2 PORT DS3 CARD WITH TMC/EOC FACILITY REDUNDANCY DATA MODULE |
 |
920-00015-01 | SAI1LT0 SAI1LT0DAA | 2 PORT DS3 I/O |
 |
920-00014-01 9ZX-ACDX-CT3-DM 717000 800-00233-01 ACDX-CT3-DM S300-CT3-DM | SAI1KW0 SAI1KW0DAA | 2 PORT DS3 MODULE, MAPPER CARD M3/1/0 CROSS CONNECT BOARD |
 |
920-00713-01 9ZX-ACDX-FXO-DM ACDX-FXO-DM FXO | SNU4DE0 SNU4DE0BAA | 24 PORT FXO CARD |
 |
713300-REV-B0 9ZX-ACDX-XCON-DM ACDX-XCON-DM XCON 920-00003-01 | SNP7KJ0 SNP7KJ0CAA | 2400X2400 1/0 TDM DATA CROSS CONNECT CARD |
 |
920-00003-01 713300 9ZX-ACDX-XCON-DM ACDX-XCON-DM | SN3PTV0 SN3PTV0JAA | 2400X2400 1/0 TDM DATA CROSS CONNECT CARD |
 |
920-00544-01 9ZX-ACDX-CE1-DSX-DM ACDX-CE1-DSX-DM | SN3PVW0 SN3PVW0JAA | 8 PORT CHANNELIZED E1 |
 |
712100-REV-A0 | SNP7EDB SNP7EDBCAA | 8 PORT CHANNELIZED T1 MAPPER UNIT |
 |
712400-REV-B2 ACDX-CT1-CSU-DM 9ZX-ACDX-CT1-CSU-DM 920-00005-01-CSU 800-00005-01 CTMC STI-CSU | SNP7EDC SNP7EDCCAA | 8 PORT CHANNELIZED T1/E1 CSU MAPPER UNIT |
 |
920-00005-01 712400 ACDX-CT1-CSU-DM 9ZX-ACDX-CT1-CSU-DM 800-00005-01 CTMC STI-CSU ST1-CSU | SN3PUW0 SN3PUW0JAA | 8 PORT CHANNELIZED T1/E1 CSU MAPPER UNIT |
 |
714000-REV-B2 9ZX-ACDX-CT1-DSX-DM ACDX-CT1-DSX-DM CT1-DSX CTMD 800-00007-01 | SNP7LDU SNP7LDUCAA | 8 PORT CHANNELIZED T1/E1 DSX MAPPER |
 |
713200-REV-A0 | SNP7JHB SNP7JHBCAA | 8 PORT UNCHANNELIZED E1 MAPPER |
 |
920-00630-01 9ZX-ACDX-CPU-G2-DM 730000 ACDX-CPU-G2-DM CPU8 800-00265-01 | SN3PRT0 SN3PRT0JAA | 8MB CPU DATA |
 |
714300-REV-A0 | SNMCN00 SNMCN00CRA | BB CROSS CONNECT SYSTEM |
 |
714310-REV-B1 | SNMCP00 SNMCP00CRA | BB CROSS CONNECT SYSTEM |
 |
920-00020-01 9ZX-ACDX-FPB-IO ACDX-FPB-IO | SNPQCTL SNPQCTLUAA | BLANK I/O UPPER FACE PLATE |
 |
920-00019-01 9ZX-ACDX-FPB-DM ACDX-FPB-DM | SNPQCTK SNPQCTKUAA | BLANK MAPPER LOWER FACE PLATE |
 |
100-0001-401 | BLANK PLATE COVER | |
 |
712600-REV-B1 800-00002-01 9ZX-ACDX-CLOCK-IO ACDX-CLOCK-IO CLK-IO | SNP7GF0 SNP7GF0CAB | CLOCK I/O CARD |
 |
712600-REV-B3 | SNP7GF0 SNP7GF0CAC | CLOCK I/O CARD |
 |
712600-REV-C0 920-01322-01 ACDX-CLOCK-IO CLK-IO 9ZX-ACDX-CLOCK-IO 800-00002-01 | SNP7GFW SNP7GFWCAB | CLOCK I/O CARD |
 |
712600-REV-B5 | SNP7GFW SNP7GFWCAA | CLOCK I/O CARD |
 |
712600-REV-A0 CLK-IO ACDX-CLOCK-IO 9ZX-ACDX-CLOCK-IO 800-00002-01 | SNP7GF0 SNP7GF0CAA | CLOCK I/O CARD |
 |
712700-REV-B2 CPU3 | SNP7HGX SNP7HGXCAA | CPU 360 UNIT |
 |
712700-REV-A1 CPU3 | SNP7HG0 SNP7HG0CAB | CPU 360 UNIT |
 |
712700-REV-A0 CPU3 | SNP7HG0 SNP7HG0CAA | CPU 360 UNIT |
 |
731000 800-00507-01 CPU4+ | CPU4+ | |
 |
ACDX-CT3-PIO 9ZX-ACDX-CT3-PIO S300-CT3-PIO S300-CT3-P | DOUBLE SLOT T3 I/O PROTECTION ASSEMBLY1 FOR 1:1 SWITCHING | |
 |
920-02604-01 9ZX-ACDX-CHASSIS-FANTRAY ACDX-CHASSIS-FANTRAY ACDX-FAN-TRAY FTPR-1-X5 9ZX-ACDX-FAN-TRAY | SNMYAFJ SNMYAFJXAA | FAN TRAY ASSEMBLY W/ AIR FILTER |
 |
920-00017-01 9ZX-ACDX-FXS-DM ACDX-FXS-DM FXS | SAI1KS0 SAI1KS0DAA | FXS POTS |
 |
920-00018-01 9ZX-ACDX-FXS-DMRNGIO ACDX-FXS-DMRNGIO RNG-IO | SAI1KV0 SAI1KV0DAA | FXS RINGER |
 |
716300-REV-A0 9ZX-ACDX-IXCON-DM 800-00004-01 920-00004-01 ACDX-IXCON-DM IXCON S300-IXCON-DM | SNPQCBZ SNPQCBZNAA | INTELLIGENT CROSS CONNECT CARD |
|
|
716300-REV-A0 9ZX-ACDX-IXCON-DM 800-00004-01 920-00004-01 ACDX-IXCON-DM IXCON S300-IXCON-DM | SNPQCBZ SNPQCBZNAB | INTELLIGENT CROSS CONNECT CARD |
 |
712000-REV-A0 920-00012-01 713000 9ZX-ACDX-MSU-IO ACDX-MSU-IO MSU 800-00012-01 | SNP8MN0 SNP8MN0FAA | MSU W/ 2X RJ 48 I/F AND LOWER FACE PLATE |
 |
920-00012-01 712000 713000 9ZX-ACDX-MSU-IO ACDX-MSU-IO | SNP8MN0 SNP8MN0FAB | MSU W/ 2X RJ 48 I/F AND LOWER FACE PLATE |
 |
713000-REV-A0 | SNTSHG0 SNTSHG0DAA | MSU W/ 2X RJ 48 I/F AND LOWER FACE PLATE |
 |
712200-REV-A0 9ZX-ACDX-OC3-DM ACDX-OC3-DM S155 | SNIXLM0 SNIXLM0BAA | OC 3 SONET ONU |
 |
712200-REV-B0 | SNIXLM0 SNIXLM0BAB | OC 3 SONET ONU |
 |
716900-REV-A0 | SNP8T70 SNP8T70FAA | OPTICAL LINE INTERFACE |
 |
920-01322-01-S-A 9ZX-ACDX-CLOCK-IO | SN3PSU0 SN3PSU0JAA | STRATUM 3 CLOCK |
 |
920-00714-01 9ZX-ACDX-STS1-DM ACDX-STS1-DM S300-STS1-DM | SACPRX0 SACPRX0DAA | STS 1 MODULE |
 |
920-00715-01 9ZX-ACDX-STS1-PIO ACDX-STS1-PIO | SAI1MX0 SAI1MX0DAA | STS 1 PROTECTION MODULE |
 |
714330-REV-A2 | SNMCS00 SNMCS00DRA | SYSTEM CHASSIS |
 |
714340-REV-A1 SNMXY00GRA SYSC 9ZX-ACDX-CHASSIS ACDX-CHASSIS 920-00009-01 | SNMCS00 SNMCS00DRB | SYSTEM CHASSIS |
 |
712300-REV-A1 920-00006-01 9ZX-ACDX-CET1-IO ACDX-CET1-IO TE-IO 800-00006-01 | SNP7FE0 SNP7FE0CAB | T1/E1 I/O MODULE |
 |
712300-REV-A0 TE-IO 920-00006-01 ACDX-CET1-IO 9ZX-ACDX-CET1-IO 800-00006-01 | SNP7FE0 SNP7FE0CAA | T1/E1 I/O MODULE |
 |
920-00006-01-S-A | SNP7FE0 SNP7FE0CAC | T1/E1 I/O MODULE |
 |
920-00013-01 S-A 714700 9ZX-ACDX-CET1-PIO ACDX-CET1-PIO TE-IOP | SNP7NM0 SNP7NM0CAB | T1/E1 I/O PROTECTION CARD |
