The Lineage 2000 Power System (also LNG-2000) was originally a Lucent Technologies power system developed by Lineage Power as a general-use, +/-24 volt or -48 volt DC output power system for telecommunications applications requiring up to 9600 amperes of rectifier output capacity. The system was sold to Tyco Electronics in December 2001. In 2005, however, Tyco and Lucent (now Alcatel-Lucent) signed a Teaming Agreement to bundle power products with Alcatel-Lucent Solutions, including the Lineage 2000 Power System. Items sold after 2001 have subsequently been branded Tyco while items sold before 2001 as Lucent Technologies.

LINEAGE 2000 Product Manual
    PartHECIDescription


    PWMYAGL PWMYAGLAAA+24V DC DISTRIBUTION

    PWBYATT PWBYATTAZZ48V BATTERY PLT

    PWBYATS PWBYATSAZZ48V BATTERY PLT

    PWBYAUR PWBYAURAZZ48V BATTERY PLT

    PWBCFE0 PWBCFE01ZZ48V FR MTD CPS EQUIPMENT

    PWPQAN3 PWPQAN3AAA48V LOW DISC

    PBMBX00 PBMBX00CRA15FT BAT STD CA EXTN

    PBMBV00 PBMBV00CRA15FT BAT STD EXTN ASSEMBLY

    PBMBS00 PBMBS00CRA15FT RND CELL BAT STD

    PBMBU00 PBMBU00CRA15FT RND CELL BAT STD



    PWPQAKF PWPQAKFAAA208/240V AC, 48V DC, 2400W POWER UNIT



    PWPQAKF PWPQAKFAAB208/240V AC, 48V DC, 2400W POWER UNIT



    PWPQADF PWPQADFAAD224V AC, 48V DC, 2400W POWER UNIT



    PWPQADF PWPQADFAAA224V AC, 48V DC, 2400W POWER UNIT



    PWPQADF PWPQADFAAE224V AC, 48V DC, 2400W POWER UNIT



    PWPQADF PWPQADFAAB224V AC, 48V DC, 2400W POWER UNIT



    PWPQADF PWPQADFAAC224V AC, 48V DC, 2400W POWER UNIT



    PWPQADF PWPQADFAAF224V AC, 48V DC, 2400W POWER UNIT

    PWCYANJ PWCYANJAAA24V/48V BATTERY STRG DISC

    PWCYANN PWCYANNAAA24V/48V BATTERY STRG DISC

    PWCYANR PWCYANRAAA24V/48V BATTERY STRG DISC

    PWCYANM PWCYANMAAA24V/48V BATTERY STRG DISC

    PWCYANH PWCYANHAAA24V/48V BATTERY STRG DISC

    PWCYANL PWCYANLAAA24V/48V BATTERY STRG DISC

    PWCYANK PWCYANKAAA24V/48V BATTERY STRG DISC

    PWCYANP PWCYANPAAA24V/48V BATTERY STRG DISC



    PWDQAGB PWDQAGBUAA400 AMP RECTIFIER


    PWDQAGD PWDQAGDUAB400 AMP RECTIFIER


    PWDQAGB PWDQAGBUAB400 AMP RECTIFIER



    PWDQAGA PWDQAGAUAA400 AMP RECTIFIER


    PWDQAGC PWDQAGCUAA400 AMP RECTIFIER



    PWDQAGD PWDQAGDUAA400 AMP RECTIFIER

    PWBYATG PWBYATGAAA48V BATTERY PLT

    PWBYAPY PWBYAPYAAA48V BATTERY PLT


    PWPQANR PWPQANRAAA48V I/O BOARD


    PWPQANR PWPQANRAAB48V I/O BOARD


    PWPQANR PWPQANRAAC48V I/O BOARD

    PWMYAHL PWMYAHLAAA48V IN RSV UNIT


    48V RECTIFIER/RINGER SHELF

    PBMBW00 PBMBW00CRA7.5FT BAT STD CA EXTN

    PBMBT00 PBMBT00CRA7.5FT RND CELL BAT STD

    PWMYASN PWMYASNAAAAC INTERFACE UNIT

    PWMYAUD PWMYAUDAAAAC INTERFACE UNIT

    PWMYAUE PWMYAUEAAAAC INTERFACE UNIT

    PWMYAT2 PWMYAT2AAAAC INTERFACE UNIT

    PWMYAUD PWMYAUDAABAC INTERFACE UNIT

    PWMYAS5 PWMYAS5AAAAC INTERFACE UNIT

    PWMYAUJ PWMYAUJAAAAC INTERFACE UNIT

    PWMYAS6 PWMYAS6AAAAC INTERFACE UNIT

    PWMYASP PWMYASPAAAAC INTERFACE UNIT
